A drawing titled "Appendix C of the Program: Jefferson National Expansion Memorial Competition: Cross-Section Profiles of the Memorial Area: Showing Railroad and Interstate Highway Proposals." The four cross-section profiles of roads in St. Louis, Missouri include a sketch of the Old Courthouse, a proposed interstate highway, a proposed railroad tunnel, the existing elevated railroad, the ground line, the approximate rock line, the high water line of 1844, and other details. Handwriting on the back reads: "Removed from O.F. 234-C, ltr, 6-25-47."
